4. Web Configuration
AirLive N.MINI User’s Manual 35
4.2.7 WPS
Disable WPS Check the box to disable the WPS function, default setting is
enabled.
WPS Status Here shows the current status of the WPS function. Default
setting is Configured, click Reset to UnConfigured to
re-configured the WPS connection.
Self-PIN Number Here shows the 8-digit numbers PIN code of the router itself.
Enter the Self-PIN Number to client (Registrar) end and click the
PIN button at the client end to make a WPS connection. It will
connect with the wireless router within two minutes and get IP
address.
Push Button
Configuration Click Start PBC button (or press the physical WPS button on the
Wireless Router once), meanwhile, the client should also click the
PBC button simultaneously within 2 minutes.
Current Key Info This table shows the security status of the Wireless Router. If user
would like to set up the security, please go to Wireless > Security.
