AirLive N.MINI - Manual (Page 35)

4. Web Configuration
AirLive N.MINI User’s Manual 28
4.2.5 WDS Settings
Wireless Distribution System uses wireless media to communicate with other APs, like the
Ethernet does. To do this, you must set these APs in the same channel and set MAC
address of other APs which you want to communicate with in the table and then enable the
WDS.
To use WDS function:
1. The APs must support WDS function.
2. To set the same SSID (Network name).
3. The channel must be set to the same on the APs.
4. To set the same Wireless MAC address (BSSID) on the APs.
5. To set same security (WEP or WPA) on the APs.
To setup WDS must use the same wireless products (the same model will
be better); due to different wireless products might support different WDS
settings.
Thus, it is suggested that to use the same wireless products that support
WDS function.
Note
