AirLive N.MINI User Manual
Page 28
4. Web Configuration
AirLive N.MINI User’s Manual
21
Channel Width
This function will be available under 2.4GHz (N), 2.4GHz (G+N),
2.4GHz (B+G+N) mode. Select 20MHz the channel number will
be form 5~11 and auto; Select 40MHz channel width the channel
number will be form 1~11 and auto. Default is 40MHz.
Control Sideband
This function will be available under 2.4GHz (N), 2.4GHz (G+N),
2.4GHz (B+G+N) mode. Select upper or lower form the pull-down
list, default is upper.
Channel Number
The channel number base on the channel width you select.
Broadcast SSID
Enabled: This Wireless Router will show its network name(SSID)
to stations.
Disabled: This Wireless Router will hide the network name to
stations. If stations want to connect to this Wireless Router, this
Router’s network name(SSID) should be known in advance to
make a connection.
WMM
The Wi-Fi Multiple Media function is available under 2.4GHz (B),
2.4GHz (G) and 2.4GHz (B+G) band, and it is disabled under
2.4GHz (N), 2.4GHz (G+N) and 2.4GHz (B+G+N) band.
Data Rate
There are several data rate that you can select from the pull-down
menu.
Associated Clients
Click button to show all connected clients.
Enable Mac Clone
(Single Ethernet
Client)
This function will be enabled under Client mode.
Enable Universal
Repeater Mode
(Acting as AP and
Client
simultaneously)
This function will be enabled under AP mode.
