2. Install the G.DUO
AirLive G.DUO User’s Manual
8
4. If you are using G.DUO in Gateway mode to share your xDSL or Cable modem connection,
please connect the Internet cable to “WAN port”.
2.4.1 Passive PoE Installation
If you want to supply the power by using Passive PoE, please follow the installation
diagram below. Please note that that the passive DC Injector is not included with G.DUO,
it need to be purchased separately. G.DUO uses 12V passive PoE system.
