13. Specifications
113 AirLive G.DUO User’s Manual
The specification of G.DUO is subject to change without notice. Please use the
information with caution.
13.1 Hardware Features
13.1.1 General Hardware Feature
„ Realtek Dual 11g/b Chipset
„ 4MB Flash, 32MB SDRAM
„ RoHS compliant
„ 4 10/100 Mbps Ethernet Port with Auto MDI/MDI-X support
„ 12V Passive PoE Port (LAN1)
„ WAN Port (LAN1)
„ Radio1: 26dBm(South America) or 20dBm(EU) TX output power
„ Radio2: 24dBm(South America) or 20dBm(EU) TX output power
„ 7 LED indicators
„ Wall Mount Screw Holes
„ Switching DC12V Power adapter
„ Reset Button
„ 2 x R-SMA antenna conectors
13.2.1 Power Supply
„ Power Adapter Voltage : input 100~240Vac/50~60Hz , output 12V/1A
„ Advance Passive PoE (Accept 12 to 24 volts)
13.2.2 Dimension and Weight
„ Dimension: 154 x 130 x 316 mm
„ AP Unit Weight(Approximate): 280g
„ Package Weight(Approximate): 686g
