Example
The state of the condition is identical with the state of condition 2 at the rise of event
1:
Condition.FlipFlopD: ClockEvent=1; Condition=2
Condition.FlipFlopRS
The block is a one-bit memory cell (variable), whose state changes to 1 or FlipFlopRS
0 at the rise of defined events. The FlipFlopRS output can be used as a condition for
action control in rather complex
applications. It is a 2N Helios IP Automation
®
simulation of an RS-type flip-flop circuit.
Parameters
SetEvent – define the event to set the condition into the 'met' state (1).
ResetEvent – define the event to set the condition into the 'not met' state (0).
ResetValue – set the condition default value upon restart. The parameter is
optional.
Valid values:
0 – condition is not met (default value)
1 – condition is met.
Example
The condition is met at the rise of event 1 and not met at the rise of event 2:
Condition.FlipFlopRS: SetEvent=1; ResetEvent=2
