4.3. Network Parameter Setting
Remember to set the module network parameters before you start using it for
calling. There are two setting options. If the gateway has factory settings or you
know its IP address, you can connect a PC to it using a crossed Ethernet cable and
set the appropriate parameters via a web browser.
In other cases, you will surely appreciate the serial port access via a
character terminal, e.g. the HyperTerminal.
4.3.1. Serial Console Setting
Connect the module to a PC as described in the Serial console configuration
section. The main menu gets displayed on the terminal. Here select the
Configuration item and then the Network item and get the following menu:
The menu contains the following items:
•
Address – is the module IP address. If the dynamic address
assignment by the DHCP is activated, the value may not be
changed manually.
•
Network mask – is the network mask. If the dynamic address
assignment by the DHCP is activated, the value may not be
changed manually.
•
Gateway – is the default router IP address. It is used for routing
data beyond the network limits. If the dynamic address
assignment by DHCP is activated, the value may not be changed
manually.
•
DNS 1 – first DNS IP address.
