RECOMMENDED SPARE PARTS
The following list will service fleets of machines (built to current production per date on the front cover) with repair
parts which can be installed in the field. Parts from the list should be replaced when inventory is depleted to keep
service parts stock supplied. For further information, contact your JLG dealer or the JLG Industries Parts Department.
31200204
3508PS, 3509PS, 3512PS, 3513PS, 4008PS, 4009PS, 4012PS, 4013PS, 4017PS, 40.7, 40.8
12-3
Outrigger Cylinder Seal Kit, (17M), (see Figure 9-6)
1
Load Control Valve, (17M), (see Figure 9-6)
1
Fork Locking Cylinder Seal Kit, (see Figure 9-7)
1
Regulator Seal Kit, (see Figure 9-8)
1
Pressure Relief Valve Seal Kit, (see Figure 9-8)
4
Solenoid & Valve Section Seal Kit, (see Figure 9-8)
4
Flow Regulator Seal Kit, (see Figure 9-8)
1
Pressure Relief Valve Seal Kit, (see Figure 9-8)
1
Pressure Reducing Valve Seal Kit, (see Figure 9-8)
1
Hydraulic Filter Element, (see Figure 8-1)
1
Level Indicator Gauge, (see Figure 9-9)
1
Directional Valve Coil, (see Figure 9-16)
1
ELECTRICAL
Boom Joystick, (see Figure 7-6)
1
Oil Pressure Switch, (see Figure 4-2)
1
Fuel Gauge Sender, (see Figure 4-3)
1
Backup Alarm, (Before S/N 1160004670), (see Figure 10-4)
1
Backup Alarm with Grill, (S/N 1160004670 & After), (see Figure 10-4)
1
Ignition switch, (see Figure 10-2)
1
Alternator, 85A, (see Figure 4-2)
1
Starter Motor, (see Figure 4-2)
1
Signal Horn, 13V, (see Figure 10-4)
1
Temperature Switch, (see Figure 4-8)
1
Solenoid Assembly, (See Figure 4-20)
5
Switch, (see Figure 7-1)
1
Switch, (see Figure 10-3)
1
Switch, (see Figure 10-3)
1
Switch, (see Figure 10-3)
1
Speed Sensor Assembly, (see Figure 4-10)
1
MISC.
1001108819
Combined Filter Kit, (includes fuel, engine oil, return, transmission, air & secondary air
filters)
1
Key, (see Figure 10-2)
1
31200205
Operation & Safety Manual
1
31200206
Service Manual
1
31200204
Parts Manual
1
Part Number
Description
Qty./Machine
