ELECTRICAL
3508PS, 3509PS, 3512PS, 3513PS, 4008PS, 4009PS, 4012PS, 4013PS, 4017PS, 40.8, 40.9
31200204
10-36
Figure 10-12 Cable Harness
PAP3210
X113
X112
1
2
X112
CONN
POS
WIRE
DESIGNATION
(REFERENCE ONLY)
COLOR
GAUGE
(AWG)
A
PLUG
-
-
B
P CTRL PWR
RED
12
C
PLUG
-
-
D
P CTRL GND
BLACK
12
E
PLAT MODE
BLK/WHT
12
F
PLAT ON
YELLOW
18
G
KEY PLAT
ORANGE
12
H
FUNC EN SW
BROWN
18
J
GND MODE
RED/BLK
18
K
1/2 AUX
BLUE
18
L
1/2 AUX A
BLU/BLK
18
M
PLUG
-
-
N
QUICK CONN
ORANGE
18
P
QUICK CONN A
ORG/BLK
18
R
PLUG
-
-
S
PLUG
-
-
T
CAN2H
RED
18
U
CAN2L
BLACK
18
V
CAN2 SHEILD
SHIELD
18
W
PLUG
-
-
X
PLAT REC
YEL/BLK
18
X113
CONN
POS
WIRE
DESIGNATION
(REFERENCE ONLY)
COLOR
GAUGE
(AWG)
A
PLUG
-
-
B
P CTRL PWR
RED
12
C
PLUG
-
-
D
P CTRL GND
BLACK
12
E
PLAT MODE
BLK/WHT
12
F
PLAT ON
YELLOW
18
G
KEY PLAT
ORANGE
12
H
FUNC EN SW
BROWN
18
J
GND MODE
RED/BLK
18
K
1/2 AUX
BLUE
18
L
1/2 AUX A
BLU/BLK
18
M
PLUG
-
-
N
QUICK CONN
ORANGE
18
P
QUICK CONN A
ORG/BLK
18
R
PLUG
-
-
S
PLUG
-
-
T
CAN2H
RED
18
U
CAN2L
BLACK
18
V
CAN2 SHEILD
SHIELD
18
W
PLUG
-
-
X
PLAT REC
YEL/BLK
18
X112
CONN
POS
WIRE
DESIGNATION
(REFERENCE ONLY)
COLOR
GAUGE
(AWG)
A
PLUG
-
-
B
P CTRL PWR
RED
12
C
PLUG
-
-
D
P CTRL GND
BLACK
12
E
PLAT MODE
BLK/WHT
12
F
PLAT ON
YELLOW
18
G
KEY PLAT
ORANGE
12
H
FUNC EN SW
BROWN
18
J
GND MODE
RED/BLK
18
K
1/2 AUX
BLUE
18
L
1/2 AUX A
BLU/BLK
18
M
PLUG
-
-
N
QUICK CONN
ORANGE
18
P
QUICK CONN A
ORG/BLK
18
R
PLUG
-
-
S
PLUG
-
-
T
CAN2H
RED
18
U
CAN2L
BLACK
18
V
CAN2 SHEILD
SHIELD
18
W
PLUG
-
-
X
PLUG
-
-
X113
CONN
POS
WIRE
DESIGNATION
(REFERENCE ONLY)
COLOR
GAUGE
(AWG)
A
PLUG
-
-
B
P CTRL PWR
RED
12
C
PLUG
-
-
D
P CTRL GND
BLACK
12
E
PLAT MODE
BLK/WHT
12
F
PLAT ON
YELLOW
18
G
KEY PLAT
ORANGE
12
H
FUNC EN SW
BROWN
18
J
GND MODE
RED/BLK
18
K
1/2 AUX
BLUE
18
L
1/2 AUX A
BLU/BLK
18
M
PLUG
-
-
N
QUICK CONN
ORANGE
18
P
QUICK CONN A
ORG/BLK
18
R
PLUG
-
-
S
PLUG
-
-
T
CAN2H
RED
18
U
CAN2L
BLACK
18
V
CAN2 SHEILD
SHIELD
18
W
PLUG
-
-
X
PLUG
-
-
TO PLATFORM CABLE HANRNESS
TO CABIN HARNESS
8M, 9M, 12M, 17M 13M
13M
8M, 9M, 12M, 17M
