FRAME & ATTACHING PARTS
3508PS, 3509PS, 3512PS, 3513PS, 4008PS, 4009PS, 4012PS, 4013PS, 4017PS, 40.8, 40.9 31200204 1-14
410 Ref BRACKET, (see Figure 5-1 for details)
411 5201210 1 RIPP BOLT, 12-20mm, (torque to 125 Nm)
412 Ref SWITCH BODY, (not shown), (see Figure 10-3 for details)
413 Ref SWITCH KEY, (not shown), (see Figure 10-3 for details)
414 Ref FRAME LEVEL CYLINDER, (see Figure 9-5 for details)
0274498 Ref FRAME LEVEL STOP & BOOM STOP INSTALLATION, (if equipped),
(required in Italy), (not available to order, see items 501 thru 506 for service) A
501 443630 3 WING SCREW, M12X30
502 0903232 1 BRACKET
503 1321370 1 CLAMP
504 2902424 1 FRAME LEVEL CYLINDER STOP KIT
505 4220251 1 BOOM LEVEL STOP
506 5201010 2 RIPP BOLT, M10X20
Figure 1-3 Axle & Fender Installation (Continued)
Item Part Number Qty. Description Rev.
