DECALS

3508PS, 3509PS, 3512PS, 3513PS, 4008PS, 4009PS, 4012PS, 4013PS, 4017PS, 40.8, 40.9

31200204

11-10

502

1001107421

1

CAPACITY CHART BOOKLET, (AUS - 4009PS)

2

1001107269

1

CARRIAGE CAPACITY CHART

1001107271

1

BUCKETS CAPACITY CHART

503

1001107159

1

CAPACITY CHART BOOKLET, (AUS - 3513PS)

2

1001106667

1

CARRIAGE CAPACITY CHART

1001106670

1

BUCKETS CAPACITY CHART

504

1001106947

1

CAPACITY CHART BOOKLET, (AUS - 4013PS)

2

1001106436

1

CARRIAGE CAPACITY CHART

1001106437

1

BUCKETS CAPACITY CHART

505

1001106706

1

CAPACITY CHART BOOKLET, (AUS - 4017PS)

2

1001106377

1

CARRIAGE CAPACITY CHART

1001106379

1

BUCKETS CAPACITY CHART

506

1001095180

1

CAPACITY CHART BOOKLET, (CE - 3508PS, if equipped with frame level)

3

1001095366

1

CARRIAGE CAPACITY CHART

1001096216

1

1.0m³ BUCKET CAPACITY CHART

1001096217

1

2.0m³ BUCKET CAPACITY CHART

1001105663

1

3.4m TRUSS BOOM CAPACITY CHART

1001105664

1

FORK MOUNTED HOOK CAPACITY CHART

1001096221

1

3.6m TRUSS BOOM CAPACITY CHART

1001096220

1

SIDE SHIFT CARRIAGE CAPACITY CHART

507

1001095179

1

CAPACITY CHART BOOKLET, (CE - 3508PS, not equipped with frame level)

3

1001095365

1

CARRIAGE CAPACITY CHART

1001096210

1

1.0m³ BUCKET CAPACITY CHART

1001096211

1

2.0m³ BUCKET CAPACITY CHART

1001105668

1

3.4m TRUSS BOOM CAPACITY CHART

1001105669

1

FORK MOUNTED HOOK CAPACITY CHART

1001096215

1

3.6m TRUSS BOOM CAPACITY CHART

1001096214

1

SIDE SHIFT CARRIAGE CAPACITY CHART

508

1001095182

1

CAPACITY CHART BOOKLET, (CE - 4008PS, if equipped with frame level)

3

1001095368

1

CARRIAGE CAPACITY CHART

1001096228

1

1.0m³ BUCKET CAPACITY CHART

1001096229

1

2.0m³ BUCKET CAPACITY CHART

1001105665

1

3.4m TRUSS BOOM CAPACITY CHART

1001105666

1

FORK MOUNTED HOOK CAPACITY CHART

1001096233

1

3.6m TRUSS BOOM CAPACITY CHART

1001096232

1

SIDE SHIFT CARRIAGE CAPACITY CHART

509

1001095181

1

CAPACITY CHART BOOKLET, (CE - 4008PS, not equipped with frame level)

3

1001095367

1

CARRIAGE CAPACITY CHART

1001096222

1

1.0m³ BUCKET CAPACITY CHART

1001096223

1

2,0m³ BUCKET CAPACITY CHART

1001105670

1

3.4m TRUSS BOOM CAPACITY CHART

1001105671

1

FORK MOUNTED HOOK CAPACITY CHART

1001096227

1

3.6m TRUSS BOOM CAPACITY CHART

1001096226

1

SIDE SHIFT CARRIAGE CAPACITY CHART

510

1001095183

1

CAPACITY CHART BOOKLET, (CE - 3509PS)

4

1001095369

1

CARRIAGE CAPACITY CHART

1001096234

1

1.0m³ BUCKET CAPACITY CHART

1001096235

1

2.0m³ BUCKET CAPACITY CHART

1001105415

1

3.4m TRUSS BOOM CAPACITY CHART

Figure 11-2 Decals - Cab (Continued)

Item

Part Number

Qty.

Description

Rev.
