CAB
3508PS, 3509PS, 3512PS, 3513PS, 4008PS, 4009PS, 4012PS, 4013PS, 4017PS, 40.8, 40.9
31200204
6-24
214
70021967
1
ELBOW
3380769
Ref
HVAC COVER PLATE INSTALLATION, (not available to order, see items 301
thru 306 for service)
A
301
0760608
4
HEX HD CAPSCREW, 6X16mm
302
0903627
2
BRACKET, (3508PS, 3509PS, 3512PS, 3513PS, 4008PS, 4009PS, 4012PS,
4013PS & 4017PS)
0903627B
2
BRACKET, (40.8 & 40.9)
303
2080086
4
RIVNUT, 6X1.25mm
304
3380737
1
HVAC PLATE
305
4191406
4
SCREW, 4X12mm
306
4831700
4
SPRING LOCKWASHER, 6mm
307
3759535
6
CLAMP
Figure 6-8 Air Conditioning Unit Installation (Continued)
Item
Part Number
Qty.
Description
Rev.
