ELECTRICAL
3508PS, 3509PS, 3512PS, 3513PS, 4008PS, 4009PS, 4012PS, 4013PS, 4017PS, 40.8, 40.9
31200204
10-28
Figure 10-8 Boom Harness Auxiliary Electrical Adapter
PAP3230
C
CONN
POS
WIRE
DESIGNATION
COLOR /
GAUGE
1
GND
<
BRN / 1.5mm
B
CONN
POS
WIRE
DESIGNATION
COLOR /
GAUGE
1
PWR
<
RED / 1.5mm
A
CONN
POS
WIRE
DESIGNATION
COLOR /
GAUGE
1
PWR
2
GND
<
RED / 1.5mm
<
BRN / 1.5mm
1
A
B
C
TO BOOM AUX HARNESS ASSY
