JLG 3508PS User Manual
Page 238
CAB
3508PS, 3509PS, 3512PS, 3513PS, 4008PS, 4009PS, 4012PS, 4013PS, 4017PS, 40.8, 40.9
31200204
6-8
Item
Part Number
Qty.
Description
Rev.
1040060
1
CAB ASSEMBLY, (3508PS, 3509PS, 3512PS, 3513PS, 4008PS, 4009PS,
4012PS & 4013PS Before S/N 1160005993 excluding 1160005949 &
1160005950), (4017PS Before S/N 1160005937 including 1160005952,
11160005960, 1160005963, 116000966 & 1160005978), (includes items 1 thru
11, 13 thru 44, 48 thru 52 & 54 thru 72)
P
1001128136
1
CAB ASSEMBLY, (3508PS, 3509PS, 3512PS, 3513PS, 4008PS, 4009PS,
4012PS & 4013PS S/N 1160005993 & After including 1160005949 &
1160005950), (4017PS S/N 1160005937 & After excluding 1160005952,
11160005960, 1160005963, 116000966 & 1160005978), (includes items 1 thru
11, 13 thru 44, 48 thru 52 & 54 thru 72)
C
1001106538
1
CAB ASSEMBLY, (40.8PS & 40.9PS Before S/N 1160005993 excluding
1160005949 & 1160005950), (includes items 1 thru 11, 13 thru 44, 48 thru 52 &
54 thru 71)
K
1001139511
1
CAB ASSEMBLY, (40.8PS & 40.9PS S/N 1160005993 & After including
1160005949 & 1160005950), (includes items 1 thru 11, 13 thru 44, 48 thru 52 &
54 thru 71)
A
1
Ref
BRAKE PEDAL, (see Figure 7-2 for details)
2
Ref
CAB INTERIOR INSTALLATION, (see Figure 6-3 for details)
3
321779
2
RING
4
0498748
6
LOCKWASHER, 7mm
5
0760608
2
HEX HD CAPSCREW, 6-1.0X16mm
6
0760812
2
HEX HD CAPSCREW, 8-1.25X25mm
7
0761008
2
HEX HD CAPSCREW, 10-1.50X16mm
8
845749
2
RIVET
9
0879192
4
PIN
10
Ref
WASHER, 25mm, (see Figure 7-2 for details)
11
Ref
REAR WINDOW BRACKET, (see Figure 6-4 for details)
12
0903674
1
BRACKET, (Before S/N 1160005851)
13
1000331
1
RUBBER STOP
14
1040055
1
CAB
15
Ref
CIRCLIP, (see Figure 7-2 for details)
16
Ref
STEERING WHEEL ASSY, (see Figure 7-1 for details)
17
Ref
STEERING COLUMN, (see Figure 7-1 for details)
18
Ref
ELECTRICAL INSTALLATION, (see Figure 10-2 for details)
19
2080080
5
HEX RIVNUT, 6X1.0
20
Ref
ROUND RIVNUT, 6X1.25, (see Figure 6-4 for details)
21
2080087
9
ROUND RIVNUT, 6X1.25
22
2080088
6
ROUND RIVNUT, 8X1.25
23
2440675
1
RIPP NUT, 12mm
24
Ref
FRONT WINDOW, (see Figure 6-4 for details)
25
Ref
LH REAR WINDOW, (see Figure 6-4 for details)
26
Ref
RH REAR WINDOW, (see Figure 6-4 for details)
27
Ref
RH SIDE WINDOW, (see Figure 6-4 for details)
28
Ref
REAR WINDOW ASSY, (see Figure 6-4 for details)
29
2480082
2
WINDOW PIN
30
2540051
4
GROMMET
34
2902506
1
REAR VIEW MIRROR KIT, (includes items 101 thru 106)
A
35
3290605
1
HEX LOCKNUT, M6X1
36
Ref
CAB DOOR ASSY, (see Figure 6-4 for details)
37
Ref
THROTTLE INSTALLATION, (see Figure 7-3 for details)
