SECTION 1 - FRAME
3121646
E400An/E400AJP/E400AJPn/M400AJP/M400AJPn
75
FIGURE 1-28. VALVE INSTALLATION - FRAME MOUNTED - E400AJP - E400AJPN
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001167096
Ref
CONTROL VALVE INSTALLATION - E400AJP/E400AJPn
E
1
0100011
AR
Compound, Locking
5
0641606
2
Bolt, 3/8-16 X 3/4
6
0641610
2
Bolt, 3/8-16 X 1-1/4
7
0641807
1
Bolt, 1/2-13 X 7/8
14
4711400
1
Washer, 1/4
15
4711600
6
Washer, 3/8
16
4711800
1
Washer, 1/2
18
1001097506
1
Brake/Steer Control Valve Assembly (See BRAKE/STEER VALVE
ASSEMBLY for Breakdown)
23
1001166420
1
Bracket, Mounting
24
1001170991
1
Harness Assembly - Brake/Steer Control Valve (Not Shown - See
ELECTRICAL SECTION for Breakdown)
26
0641404
1
Bolt, 1/4-20 x 1/2
27
4240032
1
Tie-Strap (Not Shown)
28
1320040
1
Clamp
29
88662523
2
Nut, Tinnerman
