SECTION 1 - FRAME
3121646
E400An/E400AJP/E400AJPn/M400AJP/M400AJPn
73
FIGURE 1-27. VALVE INSTALLATION - FRAME MOUNTED - E400AN
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001166438
Ref
CONTROL VALVE INSTALLATION - E400An
D
1
0100011
AR
Compound, Locking
4
0641606
6
Bolt, 3/8-16 X 3/4
5
0641610
2
Bolt, 3/8-16 X 1-1/4
6
0641807
1
Bolt, 1/2-13 X 7/8
12
3311605
2
Nut, Lock, 3/8-16
13
4711400
1
Washer, 1/4
14
4711600
4
Washer, 3/8
15
4711800
1
Washer, 1/2
17
1001097506
1
Brake/Steer Control Valve Assembly (See BRAKE/STEER VALVE
ASSEMBLY for Breakdown)
21
1001166420
1
Bracket, Mounting
22
1001170991
1
Harness Assembly - Brake/Steer Control Valve (Not Shown - See
ELECTRICAL SECTION for Breakdown)
24
88662523
2
Nut, Tinnerman
25
1320040
1
Clamp
26
0641404
1
Bolt, 1/4-20 x 1/2
27
4240032
1
Tie, Strap (Not Shown)
