SECTION 6 - CYLINDER
3121646 E400An/E400AJP/E400AJPn/M400AJP/M400AJPn 303
FIGURE 6-14. TELESCOPE CYLINDER ASSEMBLY - E400AJP - E400AJPN - M400AJP - M400AJPN
ITEM PART NUMBER QTY DESCRIPTION REV
1683911 Ref TELESCOPE CYLINDER ASSEMBLY -
E400AJP/E400AJPn/M400AJP/M400AJPn 4
1 1683912 1 Barrel, Weldment
1A 1120110 1 Cap, End
2 1683980 1 Rod, Weldment
4 1683584 1 Head
5 4567963 1 Spacer
6 4640807 1 Counterbalance Valve Assembly (See COUNTERBALANCE
VALVE ASSEMBLY for Breakdown)
7 0641512 4 Bolt, 5/16-18 X 1-1/2
8 2220883 2 Plug
9 3951402 1 Setscrew 1/4-20 X 1/4
10 3322205 1 Nut, Lock, 3/4-16
11 See Note 1 Ring, Back-up (Note: Use p/n 2901903)
12 See Note 2 Ring, Wear (Note: Use p/n 2901903)
13 See Note 1 Seal, Cap (Note: Use p/n 2901903)
14 See Note 1 O-Ring (Note: Use p/n 2901903)
15 See Note 1 Ring, Wear (Note: Use p/n 2901903)
16 See Note 1 O-Ring (Note: Use p/n 2901903)
17 See Note 1 Seal, Rod (Note: Use p/n 2901903)
18 See Note 1 Wiper, Rod (Note: Use p/n 2901903)
19 0100011 AR Compound, Locking
21 2220628 1 Fitting, 90 JIC/ORB
22 2220516 1 Fitting, Cap
23 3340882 2 Pad
24 0641424 2 Bolt, 1/4-20 x 3
25 2220596 1 Fitting, 90 JIC/ORB
26 2220517 1 Fitting, Cap
27 3311405 2 Nut, 1/4-20
28 4751400 4 Washer, 1/4
29 0100038 AR Primer, Locking
30 0100035 AR Compound, Locking
31 1120110 1 Cap, End
100 2901903 1 Seal Kit (Includes Items 11-18)
