SECTION 6 - CYLINDER
3121646 E400An/E400AJP/E400AJPn/M400AJP/M400AJPn 281
FIGURE 6-3. LIFT CYLINDER ASSEMBLY - LOWER - E400AJP - E400AJPN - M400AJP - M400AJPN
ITEM PART NUMBER QTY DESCRIPTION REV
1684451 Ref LIFT CYLINDER ASSEMBLY - LOWER -
E400AJP/E400AJPn/M400AJP/M400AJPn D
1 0100011 AR Compound, Locking
2 0100035 1 Compound, Locking
4 0961950 4 Bushing
5 1120094 1 Retainer
6 1683710 1 Head
7 1683940 1 Barrel, Weldment
8 1683941 1 Rod, Weldment
9 3480241 1 Piston
10 3900170 1 Setscrew
12 See Note 2 Ring, Wear (Note: Use p/n 2901806)
13 See Note 3 Ring, Wear (Note: Use p/n 2901806)
14 See Note 1 O-Ring (Note: Use p/n 2901806)
15 See Note 1 O-Ring (Note: Use p/n 2901806)
16 See Note 1 Seal, Piston (Note: Use p/n 2901806)
17 See Note 1 Wiper, Rod (Note: Use p/n 2901806)
18 See Note 1 Seal, Rod
19 3300281 1 Nut
20 4566432 1 Spacer
21 4640634 1 Cartridge, Holding Valve
21 2900770 1 Seal Kit - 4640634 Valve
22 4641386 1 Cartridge, Holding Valve
22 7011376 1 Seal Kit - 4641386 Valve
23 0100038 1 Primer, Locking
100 2901806 1 Seal Kit (Includes Items 12-18)
