Page 201
SECTION 4 - BOOM
3121646
E400An/E400AJP/E400AJPn/M400AJP/M400AJPn
201
FIGURE 4-11. CABLES AND CLAMPS INSTALLATION
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
0259970
Ref
CABLES AND CLAMPS INSTALLATION -
E400AJP/E400AJPn/M400AJP/M400AJPn
D
1
4922496
1
Harness Assembly - Upper Boom (See ELECTRICAL SECTION
for Breakdown)
2
4922363
1
Harness Assembly - Lower Boom (See ELECTRICAL SECTION
for Breakdown)
3
4460754
1
Connector
4
1320260
2
Block, Hose Clamp
5
0561317
1
Block, Hose Clamp
6
4460753
1
Connector
7
3571462
1
Shield
8
0641410
1
Bolt, 1/4-20 x 1-1/4
9
3311405
1
Nut, Lock, 1/4-20
10
4751500
5
Washer, 5/16
11
4751400
12
Washer, 1/4
12
3311401
6
Nut, 1/4-20
13
0641514
3
Bolt, 5/16-18 x 1-3/4
14
0100011
AR
Compound, Locking
15
4060805
1
Trim, 1/4
16
4060808
8
Trim, 1/2
17
4240099
30
Tie-Strap
18
0561385
1
Block, Hose Clamp
19
0561386
1
Block, Hose Clamp
20
3311505
1
Nut, Lock, 5/16-18
21
4566243
1
Roller
22
0641560
1
Bolt, 5/16-18 x 7-1/2
23
4300140
2
Stud, Weld, 5/16-18 x 3-5/8
24
0561384
1
Block, Hose Clamp
25
1670697
1
Cover, Hose
26
0630467
4
Capscrew, Button, 5-16-18 x 1/2
27
3300151
6
Nut, Acorn, 1/4-20
28
1320043
1
Clamp, Cable
29
0100019
AR
Compound, Locking
30
4100067
1
Sleeve
31
4100065
1
Sleeve
