SECTION 6 - CYLINDER
3121646 E400An/E400AJP/E400AJPn/M400AJP/M400AJPn 283
FIGURE 6-4. LIFT CYLINDER ASSEMBLY - MID - E400AN
ITEM PART NUMBER QTY DESCRIPTION REV
1684454 Ref LIFT CYLINDER ASSEMBLY - MID - E400An A
1 0100011 AR Compound, Locking
2 0100035 AR Compound, Locking
3 0100038 AR Primer, Locking
4 0961950 4 Bushing
5 1120108 1 Retainer
6 1681344 1 Head
7 1684025 1 Barrel, Weldment
8 1684026 1 Rod, Weldment
9 2220885 2 Plug
10 3300279 1 Nut
11 3480240 1 Piston
12 3900170 1 Setscrew
13 3951402 1 Setscrew, 1/4-20 x 1/4
14 4565994 1 Spacer
15 4640634 1 Cartridge, Holding Valve
15 2900770 1 Seal Kit - 4640634 Valve
16 4641386 1 Cartridge, Holding Valve
16 7011376 1 Seal Kit - 4641386 Valve
17 4740394 1 Washer
100 2902419 1 Seal Kit (Includes Items 101-107)
101 See Note 1 Ring, Wear (Note: Use p/n 2902419)
102 See Note 2 Ring, Wear (Note: Use p/n 2902419)
103 See Note 1 O-Ring (Note: Use p/n 2902419)
104 See Note 1 O-Ring (Note: Use p/n 2902419)
105 See Note 1 Wiper, Rod (Note: Use p/n 2902419)
106 See Note 1 Seal, Piston (Note: Use p/n 2902419)
107 See Note 1 Seal, Rod (Note: Use p/n 2902419)
