SECTION 4 - BOOM
3121646 E400An/E400AJP/E400AJPn/M400AJP/M400AJPn 195
FIGURE 4-8. ROTATOR ASSEMBLY - E400AJP - E400AJPN - M400AJP - M400AJPN
ITEM PART NUMBER QTY DESCRIPTION REV
0060065 Ref ROTATOR ASSEMBLY - MAIN BOOM TO JIB C
1 See Note 1 Case/Bracket Weldment (Note: Not Available - Purchase Complete
Assembly)
2 7017167 1 Shaft
3 7017168 1 Piston Sleeve
4 7017169 1 Cap, End
5 See Note 3 Capscrew, 1/4-20, Grade 8 (Note: Not Available - Purchase
Locally)
7 7017173 1 Tie Rod Assembly
20 See Note 1 Seal, Rod (Note: Use Item 52)
22 See Note 1 Seal, Piston (Note: Use Item 52)
24 See Note 1 Seal, Cap (Note: Use Item 52)
25 See Note 2 Packing, Bearing (Note: Use Item 52)
26 See Note 2 Seal (Note: Use Item 52)
27 See Note 1 Ring, Back-Up (Note: Use Item 52)
32 See Note 2 Bearing, Shaft (Note: Use Item 51)
34 See Note 2 Washer, Thrust (Note: Use Item 51)
41 7017172 1 Counterbalance Valve Assembly
41A 7017192 2 Valve, Cartridge (No Seal Kit Available)
42 See Note 2 Bushing, Shaft (Note: Not Available for Purchase)
51 7017178 1 Bearing Kit (Includes Items 32-34)
52 7017165 1 Seal Kit - Standard (Includes Items 20,22 & 24-27,
52 70000340 1 Seal Kit - Low Temperature (Includes Items 20,22 & 24-27)
53 7017179 1 Hardware Kit
