Page 105
SECTION 1 - FRAME
3121646
E400An/E400AJP/E400AJPn/M400AJP/M400AJPn
105
FIGURE 1-43. INVERTER INSTALLATION - E400AJP - M400AJP
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001167024
Ref
INVERTER INSTALLATION
C
1
0100011
AR
Compound, Locking
2
0641406
8
Bolt, 1/4-20 X 3/4
3
0641614
4
Bolt, 3/8-16 X 1-3/4
4
1060801
1
Cable, Battery
5
1060802
1
Cable, Ground
6
1670953
1
Cover
7
2460037
1
Inverter
8
2820035
10 ft/3.1m
Insulate, Tubing
9
3300353
4
Nut, Tinnerman
10
3311405
4
Nut, Lock, 1/4-20
11
3311605
4
Nut, Lock, 3/8-16
12
4060805
6 in
/150mm
Shield, Flex Trim
13
4460426
1
Connector, Strain Relief
14
4751400
4
Washer, 1/4
15
4751600
8
Washer, 3/8
16
4460078
1
Terminal
18
4922390
1
Harness, Inverter (See ELECTRICAL SECTION for Breakdown)
(SN 0300189901 through 0300193793)
18
1001182296
1
Harness, Inverter (See ELECTRICAL SECTION for Breakdown)
(SN 0300193794 to Present)
19
1001167014
1
Bracket
20
1701642
1
Decal - Arrow (SN 0300193794 to Present)
