SECTION 8 - ELECTRICAL
3121646
E400An/E400AJP/E400AJPn/M400AJP/M400AJPn
329
FIGURE 8-4. CONTACTOR CABLE KIT - E400AN - E400AJP - E400AJPN - UL LISTED
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001176309
Ref
CONTACTOR CABLE KIT - E400An/E400AJP/E400AJPn - UL
LISTED
A
101
1060092
6
Cable, Battery
102
1060835
1
Cable, Electrical (Motor B S2 to Motor A S1)
103
1060836
1
Cable, Electrical (Motor B A1 to Contactor Plate MB2)
104
1060837
1
Cable, Electrical (Motor A A2 to Contactor Plate MA2)
105
1001167426
1
Cable, Electrical (Motor B S1 to Contactor Plate SA1)
106
1060839
1
Cable, Electrical (Power Module A to Contactor Plate)
107
1060840
1
Cable, Electrical (Power Module B+ to Contactor Plate)
108
1060841
1
Cable, Electrical (Motor B A2 to Contactor Plate MB1)
109
1060842
1
Cable, Electrical (Motor A A1 to Contactor Plate MA1)
110
1001167431
1
Cable, Electrical (Motor A S2 to Contactor Plate SB1)
111
1001171292
1
Cable, Electrical (Contactor Plate P2 to Hydraulic Pump Motor +)
112
1001171291
1
Cable, Electrical (Power Module to Hydraulic Pump Motor -)
113
1060810
1
Cable, Electrical (Power Module to Batteries)
114
1060811
1
Cable, Electrical (Battery to Battery)
115
1060847
1
Cable, Electrical (Jumper, Fuse)
201
1060809
1
Cable, Battery
