SECTION 9 - DECALS
3121646
E400An/E400AJP/E400AJPn/M400AJP/M400AJPn
463
FIGURE 9-7. DECAL INSTALLATION - JAPANESE SPEC - E400AN - E400AJP - E400AJPN
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001178372
Ref
DECAL INSTALLATION - JAPANESE SPEC -
E400An/E400AJP/E400AJPn
A
2
1703938
2
Decal - Electrocution
3
1704900
2
Decal - Model Designation (E400An)
3
1704791
2
Decal - Model Designation (E400AJP)
3
1704792
2
Decal - Model Designation (E400AJPn)
4
1703932
1
Decal - Danger/Caution
7
See Note
1
Nameplate - Serial Number (Note: Not Available for Purchase)
8
3820001
2
Rivet
9
1701504
1
Decal - Hydraulic Oil
10
1701642
2
Decal - Arrow
11
1703926
1
Decal - Caution/Danger
13
1701644
2
Decal - Charger
15
1703980
1
Decal - Footswitch
16
1704277
2
Decal - Attach Lanyard
19
0961127
1
Bushing, Snap
21
0100010
AR
Adhesive
22
1701691
4
Decal - No Step
23
1001104864
1
Decal - Manual Descent
25
1001173577
1
Decal - Cable Routing
26
1704253
1
Decal - Key Platform
27
1704417
1
Decal - Charger
28
1704431
1
Decal - Battery Charger LED Indicator
31
0860520
1
Box, Manual Storage
32
1060279
1
Lanyard
33
0641408
1
Bolt 1/4-20 x 1
35
4751400
6
Washer, 1/4
36
3311405
5
Nut, Lock, 1/4-20
37
1701500
4
Decal - Lift
38
1701509
1
Decal - Manual
39
1704342
3
Decal - Explosion Warning
41
1703950
6
Decal - Crushing Hazard
47
1702271
1
Decal
50
1702300
4
Decal - Tie Down
52
See Note
1
Decal - Bar Code (Note: Not Available for Purchase)
53
1001121821
1
Decal - 500 LBS. Max Capacity
54
1703488
4
Decal - Tire Load (E400An)
54
1704727
4
Decal - Tire Load (E400AJP)
54
1704752
4
Decal - Tire Load (E400AJPn)
65
1001121808
2
Decal - 500 LBS. Max Capacity
77
1704412
1
Decal - Oil Type
79
1704885
2
Decal - Website
80
0641406
4
Bolt 1/4-20 x 3/4
81
1705426
1
Decal - Drive/Steer Instruction
