SECTION 2 - TURNTABLE
3121118
E600/E600J/E600JP/M600/M600J/M600JP
93
FIGURE 2-15. MAIN TERMINAL BOX ASSEMBLY AND INSTALLATION
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
0861336
Ref
MAIN TERMINAL BOX ASSEMBLY
F
1
Ref
Module Options:
1
0610139
1
Module (Use p/n 1001109497) (Prior to SN 0300072457)
1
0610166
1
Module (Use p/n 1001109497) (SN 0300072457 through
0300141893)
1
1001109497
1
Module (SN 0300141894 to Present)
2
0861317
1
Box Assembly
2A
Not Available
1
Latch
3
3300396
2
Cover, Fuse
4
3310601
10
Nut #6-32NC
5
4360070
2
Breaker, Circuit - 15Amp
6
4460007
1
Bar, Buss
7
4460426
1
Connector, Strain Relief
8
4760600
10
Lockwasher #6
10
3790012
2
O-Ring
11
4460496
2
Lockwasher, Terminal
12
4460497
2
Nut, Terminal
13
3990106
1
Limiter, Inrush Current
14
4460264
2
Jumper, Ground Bus Bar
15
4750600
4
Flatwasher #6 Regular
0259961
Ref
MAIN TERMINAL BOX INSTALLATION
B
101
0641614
4
Bolt 3/8in-16NC x 1-3/4in
102
0861336
1
Main Terminal Box Assembly (See Items 1-15 for Breakdown)
103
3311605
4
Locknut 3/8in-16NC
104
4711600
8
Flatwasher 3/8in Thin
105
0100011
AR
Locking, Compound
