SECTION 3 - BOOM
124
E600/E600J/E600JP/M600/M600J/M600JP
3121118
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
117A
7017452
1
Cartridge without Coil
117A
7017402
1
Seal Kit - 7017452 Cartridge
117A
Ref
Coil Options:
117A
7021609
2
Coil (Prior to SN 0300058444)
117A
7012944
2
Coil (SN 0300058444 to Present)
117B
7012989
1
Cartridge
117B
7012953
1
Seal Kit - 7012989 Cartridges
118
4711500
6
Flatwasher 5/16in Thin
119
4711600
2
Flatwasher 3/8in Thin
123
4846218
1
Valve Mounting Weldment
Ref
ROTATOR VALVE ASSEMBLY
4641140
Ref
Rotator Valve Assembly E600 & M600
E
201
7017452
2
Cartridge without Coils (Platform Level and Rotate)
201
7017402
2
Seal Kit - 7017452 Cartridge
201
7012944
4
Coil
202
7012914
2
Cartridge, Check (Platform Level)
202
7012918
2
Seal Kit - 7012914 Cartridge
203
7023906
2
Cartridge, Relief (Platform Level)
203
7021651
2
Seal Kit
204
7012989
1
Cartridge, Regulator (Rotate)
204
7012953
1
Seal Kit - 7012989 Cartridge
205 to 208
Not Required
0
Not Required
4641141
Ref
Rotator Valve Assembly E600J & M600J & E600JP & M600JP
F
201
7017452
3
Cartridge without Coils (Platform Level and Rotate and Jib)
201
7017402
3
Seal Kit - 7017452 Cartridge
201
7012944
6
Coil
202
7012914
2
Cartridge, Check (Platform Level)
202
7012918
2
Seal Kit - 7012914 Cartridge
203
Ref
Cartridge, Relief (Platform Level and Jib)
203
7023905
1
Cartridge, Relief (Prior to SN 0300064130)
203
7023968
1
Cartridge, Relief (SN 0300064130 to Present)
203
7021651
3
Seal Kit - 7023905/7023968 Cartridges
204
7012989
1
Cartridge, Regulator (Rotate)
204
7012953
1
Seal Kit - 7012989 Cartridge
205
7010542
1
Cartridge, Load Shuttle (Jib)
205
7010543
1
Seal Kit - 7010542 Cartridge
206
7012965
1
Cartridge, Regulator (Jib)
206
7012953
1
Seal Kit - 7012965 Cartridge
207
Ref
Cartridge, Relief (Platform Level and Jib)
207
7023905
1
Cartridge, Relief (Prior to SN 0300064130)
207
7023968
1
Cartridge, Relief (SN 0300064130 to Present)
207
7021651
1
Seal Kit - 7023905/7023968 Cartridges
208
Ref
Cartridge, Relief (Platform Level and Jib)
208
7023905
1
Cartridge, Relief (Prior to SN 0300064130)
208
7023968
1
Cartridge, Relief (SN 0300064130 to Present)
208
7021651
1
Seal Kit - 7023905/7023968 Cartridges
