SECTION 5 - CYLINDER
3121118
E600/E600J/E600JP/M600/M600J/M600JP
183
FIGURE 5-7. MASTER CYLINDER ASSEMBLY
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
MASTER CYLINDER ASSEMBLY
1683865
Ref
Master Cylinder Assembly M600
C
1
7001084
1
Locknut
2
7017284
1
O-Ring
3
7017284
1
Ring, Wear
4
7017285
1
Piston
5
7017284
1
Seal, Piston
6
7017284
1
O-Ring
7
7017286
1
Spacer
8
7017287
1
Barrel Assembly
8A
0961951
2
Bushing
9
7017288
1
Rod Assembly
9A
0961951
2
Bushing
10
7017284
1
O-Ring
11
7017284
1
Ring, Back-Up
12
7017283
1
Setscrew 1/4in-20NC x 3/8in
13
7017289
1
Guide
14
7017284
1
Seal
15
7017284
1
Wiper
50
7017284
1
Seal KIt (Includes Items 2, 3, 5, 6, 10, 11, 14 & 15)
1683866
Ref
Master Cylinder Assembly M600J & M600JP
D
101
7017278
1
Locknut
102
7017277
1
O-Ring
103
7017277
1
Ring, Wear
104
7017279
1
Piston
105
7017277
1
Seal, Piston
106
7017277
1
O-Ring
108
7017280
1
Barrel Assembly
108A
0961951
2
Bushing
109
7017281
1
Rod Assembly
109A
0961951
2
Bushing
110
7017277
1
O-Ring
111
7017277
1
Ring, Back-Up
112
7017283
1
Setscrew 1/4in-20NC x 3/8in
113
7017282
1
Guide
114
7017277
1
Seal
115
7017277
1
Wiper
150
7017277
1
Seal KIt (Includes Items 102, 103, 105, 106, 110, 111, 114 &
115)
