SECTION 4 - PLATFORM
3121118
E600/E600J/E600JP/M600/M600J/M600JP
161
FIGURE 4-10. SOFT TOUCH INSTALLATION (SIDE ENTRY PLATFORM)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
SOFT TOUCH INSTALLATION
0274323
Ref
30in x 72in (76cm x 183cm) Platform
A
0274927
Ref
36in x 72in (91cm x 183cm) Platform (W/Fall Arrest)
B
1
0100011
AR
Locking, Compound
2
0200048
2
Arm, Switch Activator
3
0630462
8
Bolt, Carriage
4
0641414
8
Bolt 1/4in-20NC x 1 3/4in
5
0731005
4
Screw #10-32NF x 5/8in
6
Ref
Bumper, Kit Options:
6
Ref
30in x 72in (76cm x 183cm) Platform:
6
0940167
1
Bumper, Kit
6
0940092
10
Bumper (Corner)
6
0940094
AR
Bumper (28ft Length)
6
Ref
36in x 72in (76cm x 183cm) Platform:
6
0940177
1
Bumper, Kit
6
0940092
8
Bumper (Corner)
6
0940094
AR
Bumper (28ft Length)
7
Ref
Cable, Electrical Options:
7
1060494
15 ft/4.6m
Cable, Electrical 12/3 (30in x 72in (76cm x 183cm) Platform)
7
1060341
23 ft/7m
Cable, Electrical 12/2 (36in x 72in (76cm x 183cm) Platform)
8
1060903
4
Wire Rope and Eyebolt Assembly
9
1702938
1
Decal - Soft Touch Override
10
3311401
8
Nut 1/4in-20NC
11
3311501
8
Nut 5/16in-18NC
12
Ref
Plate, Switch Strike Options:
12
3575705
2
30in x 72in (76cm x 183cm) Platform
12
3575359
2
36in x 72in (76cm x 183cm) Platform
13
4240099
1
Tie, Wire (Not Shown)
14
4360057
2
Switch, Limit
15
4360387
1
Switch, Push Button
16
4420068
AR
Tape, Yellow Adhesive
17
4460049
2
Connector, Strain Relief
18
4460234
AR
Terminal, Mount
19
4460425
1
Connector, Strain Relief
20
4751400
AR
Flatwasher 1/4in Regular
21
4751500
8
Flatwasher 5/16in Regular
22
4751800
8
Flatwasher 1/2in Regular
23
4846370
1
Soft Touch Rail
