SECTION 1 - FRAME
16
E600/E600J/E600JP/M600/M600J/M600JP
3121118
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
121
4070897
4
Shim #18Ga
122
4070898
2
Shim #11Ga
123
4640871
1
Lockout Valve Assembly
123
7012693
1
Seal Kit - 4640871 Valve
123
7002840
1
Anti Pin Removal Tool
124
4711400
4
Flatwasher 1/4in Thin
125
4711600
6
Flatwasher 3/8in Thin
126
4740158
1
Thrustwasher
127
4751800
4
Flatwasher 1/2in Regular
128
4846139
1
Axle Weldment
128A
0561371
2
Steer Cylinder Mounting Block Assembly
129
0100019
AR
Locking, Compound (SN 0300062044 through 0300064016)
130
3440824
4
Pin, Roll (SN 0300062044 through 0300064016)
0259942
Ref
STEERING AND VALVES INSTALLATION
H
202
0100011
AR
Locking, Compound
204
0440161
AR
Thrustwasher
205
0641606
3
Bolt 3/8in-16NC x 3/4in
206
0641607
4
Bolt 3/8in-16NC x 7/8in
208
0642030
4
Bolt 5/8in-11NC x 3-3/4in
209
0961948
4
Bushing, Garmax
210
Ref
Steer Cylinder Assembly (See CYLINDER SECTION for
Breakdown)
210
1683851
1
Steer Cylinder Assembly (Use p/n 1001140281) (Prior to SN
0300165153)
210
1001140281
1
Steer Cylinder Assembly (SN 0300165153 to Present)
213
3322202
2
Nut, Jam 3/4in-16NF
214
3323403
2
Nut, Slotted Castle 1-1/2in-12NF
215
3422817
4
Pin
216
3422819
2
Kingpin
217
3450812
2
Pin, Cotter 1/4in x 3in
218
3571709
1
Plate, Steer Cylinder Cover (Prior to SN 0300187512)
219
3841143
4
Keeper, Pin
220
3841443
2
Rod-End
222
4892000
4
Flatwasher 5/8in Hardened
223
4713400
2
Flatwasher 1-1/2in Thin
224
4740111
4
Thrustwasher
225
4751600
2
Flatwasher 3/8in (Prior to SN 0300187512)
226
4846135
2
Spindle
227
4846141
2
Tie-Rod
231
0962292
2
Bushing
239
1001156428
AR
Shim .120 (SN 0300176747 to Present)
240
1001156429
AR
Shim .060 (SN 0300176747 to Present)
241
1001156430
AR
Shim .030 (SN 0300176747 to Present)
