SECTION 1 - FRAME
36 E600/E600J/E600JP/M600/M600J/M600JP 3121118
ITEM PART NUMBER QTY DESCRIPTION REV
141 4750600 4 Flatwasher #6 Regular
142 4751000 6 Flatwasher #10 Regular (UL Spec Only)
143 4751600 1 Flatwasher 3/8in Regular
146 0840041 1 Boot, Battery Cable (UL Spec Only)
0259836 Ref FRAME SHIELDS INSTALLATION F
201 0100011 AR Locking, Compound
202 0641505 12 Bolt 5/16in-18NC x 5/8in
203 2940042 1 Latch
204 3311501 3 Nut 5/16in-18NC
205 3520064 2 Plug
206 3571797 2 Cover, Axle
207 3572055 1 Cover, Front Frame
208 3960447 4 ft/1.2m Seal, Self-Gripping
209 4751500 15 Flatwasher 5/16in Regular
210 4846161 1 Door Weldment
211 1060799 1 Cable, Lanyard
212 3311601 2 Nut 3/8in-16NC
213 0641608 1 Bolt 3/8in-16NC x 1in
214 3900283 1 Screw, Button Head 1/4in x 3/4in
215 4711400 3 Flatwasher 1/4in Thin
Ref CONTACTOR PLATE ASSEMBLY
1600294 Ref ANSI Spec E
1600300 Ref UL Spec B
Ref Note: Torque Bolts to 80in lbs replacing components.
Ref Contactor Harness Options: (See ELECTRICAL SECTION for
Breakdown)
7022003 1 ANSI Spec
7022008 1 UL Spec
Ref Posi -Track Contactor Harness Options: (See ELECTRICAL
SECTION for Breakdown)
7022004 1 ANSI Spec
Not Required 0 UL Spec
7022005 1 Harness, Shunt (See ELECTRICAL SECTION for Breakdown)
301 Ref Contactor Options: (Fwd/Rev)
301 7022002 1 ANSI Spec
301 7022007 1 UL Spec
302 Ref Contactor Options: (Main)
302 7022001 1 ANSI Spec
302 7022009 1 UL Spec
303 Ref Contactor Options: (Posi-Track)
303 7022000 1 ANSI Spec
303 7022010 1 UL Spec
