SECTION 5 - CYLINDER
3121118 E600/E600J/E600JP/M600/M600J/M600JP 185
FIGURE 5-8. STEER CYLINDER ASSEMBLY (Prior to SN 0300165153)
ITEM PART NUMBER QTY DESCRIPTION REV
1683851 Ref STEER CYLINDER ASSEMBLY D
Ref Note: Original Equipment components may have been
replaced with Service Replacement components part. Identify
p/n stamped on cylinder before ordering parts.
1 0100011 AR Locking, Compound
2 0100038 AR Primer, Locking
4 1683848 1 Rod Weldment
5 1683850 1 Barrel Weldment
6 1683898 2 Head
8 2901875 2 Ring, Wear
9 2901875 4 Ring, Wear
10 2901875 2 O-Ring
11 2901875 2 Wiper
12 2901875 2 Ring, Back-up
13 2901875 1 T-Seal
14 2901875 2 Seal
15 3760368 2 Washer, Ring
16 3931516 16 Bolt, Socket Head 5/16in-18NC x 2in
100 2901875 1 Seal Kit (Includes Items 8-14)
