SECTION 1 - FRAME
42
E600/E600J/E600JP/M600/M600J/M600JP
3121118
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
217
3450812
2
Pin, Cotter 1/4in x 3in
218
3571709
1
Plate, Steer Cylinder Cover (Prior to SN 0300187512)
219
3572490
1
Plate, Tow Bar Pivot
220
3841143
5
Keeper, Pin
221
3841443
2
Rod-End
222
3900295
1
Bolt, Shoulder 1in x 3in
223
3900296
1
Bolt, Shoulder 1in x 4-1/2in
225
4713000
2
Flatwasher 1-1/4in Thin
226
4740111
9
Thrustwasher
227
4740155
2
Thrustwasher
228
4751600
2
Flatwasher 3/8in Regular (Prior to SN 0300187512)
229
4846076
1
Tie-Rod (Left Side)
230
4846294
1
Tie-Rod (Right Side)
231
4846294
1
Link, Tow Bar
232
4892000
4
Flatwasher 5/8in Hardened
233
1001151395
AR
Shim .048 (SN 0300176747 to Present)
234
1001151428
AR
Shim .036 (SN 0300176747 to Present)
2780245
Ref
HUB ASSEMBLY
C
301
7020137
2
Cap, Dust (1 Per Assembly)
302
7020054
2
Nut, Castle (1 per Assembly)
303
7020140
2
Pin, Cotter (1 per Assembly)
304
7020055
2
Washer, Spindle (1 Per Assembly)
305
7020039
2
Cone, Bearing - Outer (1 per Assembly)
306
7020035
2
Hub (1 Per Assembly)
306A
7020036
2
Cup, Bearing - Inner(1 per Assembly)
306B
7020038
2
Cup, Bearing - Outer (1 per Assembly)
306C
7020041
18
Stud, Wheel (9 Per Assembly)
307
7020037
2
Cone, Bearing - Inner (1 per Assembly)
308
7020040
2
Seal (1 Per Assembly)
309
7020251
2
Spindle Assembly (1 Per Assembly)
310
0961951
4
Bushing, Garmax (2 Per Assembly)
311
0962292
2
Bearing, Garmax (1 Per Assembly)
Ref
TOW DECALS INSTALLATION
0270629
Ref
English Language
A
0270631
Ref
English/Spanish Combination
A
401
Ref
Decal - Warning Options:
401
1703450
1
English Language
401
1704576
1
English/Spanish Combination
402
Ref
Decal - Tow Instructions Options:
402
1704482
1
English Language
402
1704457
1
English/Spanish Combination
403
Ref
Decal - Crushing Options:
403
1704578
3
English Language
403
1704577
3
English/Spanish Combination
404
Ref
Nameplate - Steer/Tow Select Options:
404
3250872
1
English Language
404
3252693
1
English/Spanish Combination
405
3820001
4
Rivet
406
4420051
35
in/89cm
Tape, Safety
