SECTION 3 - BOOM
3121118
E600/E600J/E600JP/M600/M600J/M600JP
127
FIGURE 3-7. CABLES, CLAMPS AND LIMIT SWITCHES INSTALLATION
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
CABLE AND CLAMP INSTALLATIONS
0259952
Ref
Cable and Clamp Installations E600 & M600
F
0259953
Ref
Cable and Clamp Installations E600J & M600J
F
0259954
Ref
Cable and Clamp Installations E600JP & M600JP
I
1
0100011
AR
Locking, Compound
2
0641612
4
Bolt 3/8in-16NC x 1-1/2in
3
1060494
1
Cable, Electrical -12/3 (Use p/n 4922937)
4
1320256
1
Clamp, Block
5
2820029
3 in/7.6cm
Insulator, Heat Shrink
6
4460496
1
Lockwasher, Terminal
7
4460497
1
Nut, Terminal
8
4711600
4
Lockwasher 3/8in Thin
9
4922355
1
Harness, Boom - Lower #18-11/1STP (See ELECTRICAL
SECTION for Breakdown)
10
Ref
Harness, Boom - Upper #18-11/1STP Options (See
ELECTRICAL SECTION for Breakdown):
10
4922356
1
Harness, Boom E600 & M600
10
4922358
1
Harness, Boom E600J & M600J
10
4922360
1
Harness, Boom E600JP & M600JP (Use p/n 4922356) (Prior to
SN 0300100004)
10
4922356
1
Harness, Boom E600JP & M600JP (SN 0300100004 to
Present)
11
Ref
Harness, Rotator Valve - Upper Options (See ELECTRICAL
SECTION for Breakdown):
11
4922359
1
Harness, Rotator Valve E600 & M600
11
4922362
1
Harness, Rotator Valve E600J & M600J
11
4922357
1
Harness, Rotator Valve E600JP & M600JP
12
4922361
1
Harness, Rotator Valve - Lower (See ELECTRICAL SECTION for
Breakdown)
13
4100026
3 ft/1m
Sleeve, Hose Protector (E600JP & M600JP Only)
14
4240033
2
Tie, Wire (E600JP & M600JP Only)
15
1060494
1
Cable, Electrical - 12/3 (Use p/n 4922938)
