SECTION 4 - PLATFORM
3121118 E600/E600J/E600JP/M600/M600J/M600JP 159
FIGURE 4-9. SOFT TOUCH INSTALLATION (FRONT ENTRY PLATFORM)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref SOFT TOUCH INSTALLATION
0270516 Ref 6ft (1.83m) Platform A
0270405 Ref 8ft (2.44m) Platform A
1 0100011 AR Locking, Compound
2 0200048 2 Arm, Switch Activator
3 0630462 8 Bolt, Carriage
4 0641414 8 Bolt 1/4in-20NC x 1 3/4in
5 0731005 4 Screw #10-32NF x 5/8in
6 0940092 12 Bumper, Corner
7 0940094 2 Bumper, Center
8 1060903 4 Wire Rope and Eyebolt Assembly
9 3311401 10 Nut 1/4in-20NC
10 3311501 8 Nut 5/16in-18NC
11 3539719 2 Plate, Switch Strike
12 3941405 2 Screw 1/4in-20NC x 5/8in
13 4360057 2 Switch, Limit
14 4420068 AR Tape, Yellow Adhesive (Not Shown)
15 4460049 2 Connector, Strain Relief
16 4711400 AR Flatwasher 1/4in Thin
17 4751400 AR Flatwasher 1/4in Regular
18 4751500 12 Flatwasher 5/16in Regular
19 4751800 8 Flatwasher 1/2in Regular
20 Ref Soft Touch Rail Options:
20 4846370 1 6ft (1.83m) Platform
20 4846277 1 8ft (2.44m) Platform
