SECTION 1 - SPECIFICATIONS
3120691
– JLG Sizzor –
1-1
SECTION 1. SPECIFICATIONS
1.1
CAPACITIES
Hydraulic Oil Tank
Approximately 17 U.S. gallons (64.4 liters) w/15% air
space
Hydraulic System (Including Tank)
Approximately 20 U.S. gallons (75.7 liters)
Fuel Tank
Approximately 15 U.S. gallons (56.8 liters)
Engine Crankcase
Gasoline Engine
3.4 quarts (3.2 liters) w/filter
2.9 quarts (2.7 liters) w/o filter
Diesel Engine
6.9 quarts (6.5 liters) w/filter
6.3 quarts (6.0 liters) w/o filter
Coolant Capacity (Gasoline Engine)
3.5 U.S. gallons (13.2 liters)
1.2
COMPONENT DATA
Gasoline Engine
Manufacturer - Ford
Displacement - 1.3 liter
Low RPM - 2200
High RPM - 3000
Alternator - 55 Amp external
Battery - 85 Amphour, 550 Cold Cranking Amps
Fuel Consumption
Low RPM - 1.8 gph (6.7 lph)
High RPM - 3.0 gph (11.4 lph)
Horsepower - 40 @ 3000 RPM
Diesel Engine
Manufacturer - Deutz
Low RPM - 2000
High RPM - 3000
Alternator - 85 Amphour, 550 Cold Cranking Amps
Fuel Consumption
Low RPM - 1.3 gph (4.9 lph)
High RPM - 1.6 gph (6.0 lph)
Horsepower - 27 @ 2800 RPM
Drive/Steer System
Toe-In - Adjust to 1/4 inch (6.4 mm) overall
Drive Motor - 2.48 in.[3] (6.3 cm[3]) displacement
Drive Hub (2WD Rear) - Hub ratio 35:1
Drive Hub (4WD Rear) - Hub ratio 24:1
Drive Hub/Brake (4WD Front) - Hub ratio 24:1; brake -
spring applied, hydraulic release, release pressure - 160
psi (11 bar) initial, 190 psi (13 bar) full.
Drive Brake (2WD/4WD Rear) - Spring applied, hydraulic
release, release pressure - 150 psi (10 bar) initial, 170 psi
(12 bar) full.
Hydraulic Filter - Inline
Return - Bypass Type
25 Microns Nominal
Tires
Standard - 31 - 15.5 x 15 NHS, 8 ply, pneumatic, inflate to
60 PSI (4 bar).
Optional - 12 - 16.5 NHS, 6 ply, foam filled
Optional - 12 - 16.5 NHS, 6 ply, pneumatic, inflate to 60
PSI (4 bar).
