SECTION 1 - SPECIFICATIONS
3120691
– JLG Sizzor –
1-7
1.7
SERIAL NUMBER LOCATIONS
For machine identification, a serial number plate is affixed
to the machine. The plate is located on the right front side
of the frame rail. In addition, should the serial number
plate be damaged or missing, the machine serial number
is stamped on the top of frame between the front wheels.
1.8
LIMIT SWITCHES
The machine is equipped with the following limit switches:
High Drive Speed Cut-Out - High drive speed is cut out
when platform is raised above stowed (fully lowered) posi-
tion.
Tilt Alarm - 5° - A horn is sounded and a warning light is
illuminated when the machine is operated on a slope that
exceeds 5° with the platform raised. If the machine is oper-
ated on a 5° slope with the platform completely lowered,
only the warning light is illuminated.
1.9
CYLINDER SPECIFICATIONS
NOTE: All dimensions are given in inches (in), with the met-
ric equivalent, centimeters (cm), in parentheses.
Figure 1-3. Serial Number Location
Table 1-4. Cylinder Specifications
Description
Bore
Stroke
Rod Dia
Lift Cylinder
(25RTS/33RTS)
5.0
(12.7)
66.6
(169.2)
3.0
(7.6
Lift Cylinder
(40RTS)
5.0
(12.7)
65.6
(166.4)
3.5
(8.9
Lockout Cylinder
(Oscillating Axle)
3.0
(7.6)
3.75
(9.5)
1.25
(3.2)
Leveling Jack
Cylinder
2.0
(5.1)
14.0
(35.6)
1.25
(3.2)
Steer Cylinder
2.5
(6.4)
7.1
(18.1)
1.25
(3.2)
