SECTION 1 - SPECIFICATIONS
1-2
– JLG Sizzor –
3120691
1.3
PERFORMANCE DATA
Travel Speed
Gasoline 2 W/D - 8-10 seconds per 50 ft. (15 m)
Gasoline 4 W/D - 12-14 seconds per 50 ft. (15 m)
Diesel 2 W/D - 9-11 seconds per 50 ft. (15 m)
Diesel 4 W/D - 14-16 seconds per 50 ft. (15 m)
Gradeability
2 Wheel Drive - 25% (14°)
4 Wheel Drive - 45% (24°)
Turning Radius (Outside)
2 Wheel Steer - 18 ft.1 in. (5.51 m)
4 Wheel Steer - 11 ft. 3 in. (3.43 m)
Lift Speed
Lift up - 25RTS - 50-55 seconds
33RTS - 53-58 seconds
40RTS - 58-63 seconds
Lift down - All models - 30-40 seconds
Platform Capacity - Fixed Platform
25RTS - 2,000 lb. (910 kg)
33RTS - 1,500 lb. (680 kg)
40RTS - 1,000 lb. (455 kg)
Platform Capacity - Mechanical Platform
Extension with Deck Extended
25RTS - Main Deck - 1,250 lb (570 kg)
Extension - 500 lb (230 kg)
33RTS - Main Deck - 750 lb (340 kg)
Extension - 500 lb (230 kg)
40RTS - Main Deck - 250 lb (115 kg)
Extension - 500 lb (230 kg)
Platform Capacity - Mechanical Platform
Extension with Deck Retracted
25RTS - 1,750 lb (795 kg)
33RTS - 1,250 lb (570 kg)
40RTS - 750 lb (340 kg)
Machine Weight
25RTS - Approx. 7,600 lb. (3,445 kg)
33RTS - Approx. 8,200 lb. (3,720 kg)
40RTS - Approx. 9,200 lb. (4,175 kg)
Machine Height (Platform Lowered)
25RTS - 103.5 in. (2.6 m)
33RTS - 111.5 in. (2.8 m)
40RTS - 119.5 in. (3.0 m)
Machine Length
12 ft. 5 in. (3.78 m)
Machine Width
All Models - Standard Tires - 7 ft. 6 in. (2.29 m)
All Models - Optional Tires - 7 ft. 7 in. (2.31 m)
1.4
TORQUE REQUIREMENTS
All wheel lugs must be torqued at 90 ft lbs. every 50 hours.
NOTE: When maintenance becomes necessary or a fas-
tener has loosened, to determine proper torque
value.
1.5
LUBRICATION
NOTE: Hydraulic oils must have anti-wear qualities at least
to API Service Classification GL-3, and sufficient
chemical stability for mobile hydraulic system ser-
vice. JLG Industries recommends Mobilfluid 424
hydraulic oil, which has an SAE viscosity index of
152.
Table 1-1. Hydraulic Oil
HYDRAULIC SYSTEM OPERATING
TEMPERATURE RANGE
SAE VISCOSITY GRADE
0 to +23 degrees F
(-18 to -5 degrees C)
10W
0 to +210 degrees F
(-18 to +100 degrees C)
10W-20,10W-30
+50 to +210 degrees F
(+10 to +100 degrees C)
20W-20
