SECTION 4 - CONTROL COMPONENTS

3121163

– JLG Lift –

4-13

Shunt Assembly and Capacitors -
Remove/Install

SCR Rectifier - Remove/Install (Either Side)

Transformer Installation

Shunt Assembly and Capacitors - Remove/Install

1. Shunt Assembly

2. Spacers (2)

3. Capacitors

4. Attach Screws (4)

1

2

3

4

4

SCR Rectifier - Remove/Install

(Same Mounting on Both Sides)

1. SCR Rectifier

3. Nut/Lock Washer

2. Aluminum Mount Plate

1

2

3

Transformer Remove/Install

1. Transformer

2. Nuts/Washers (4)

3. Attach Screws

1

2

3
