SECTION 3 - BASE COMPONENTS

3-2

– JLG Lift –

3121163

3.2

PLATFORM DESCENT - BEACON AND
ALARM

Descent Beacon - Remove/Install

Descent Alarm - Remove/Install

3.3

WHEEL ASSEMBLIES

Front Caster Wheel - Remove/Install

Rear Locking Caster Wheel - Remove/Install

1. Beacon Assembly

3. Rout wires through hole in

2. Mounting Screws

base frame

1. Descent Alarm Assembly

3. Wire Terminals

2. Mounting Screws

Note: Located inside base frame, under the platform.

1. Caster Wheel Assembly 3. Base Frame (Front Member)
2. Hex Head Cap Screws

Note: Left front caster wheel shown.

1. Rear Locking Caster Wheel

3. Base Frame Caster

2. Hex Head Cap Screws

Mounting Pad

Note: Right rear locking caster shown.
