SECTION 6 - JLG CONTROL SYSTEM
3121616
– JLG Lift –
6-37
6.3 MACHINE ORIENTATION WHEN SETTING
FUNCTION SPEEDS
LIFT UP: from platform control, lowest elevation up to maxi-
mum elevation, boom retracted, jib retracted.
LIFT DOWN: from platform control, maximum elevation down
to minimum elevation, boom retracted, jib retracted.
JIB LIFT UP: from platform control, lowest jib elevation up to
maximum jib elevation, boom retracted, jib retracted.
JIB LIFT DOWN: from platform control, maximum jib elevation
down to minimum jib elevation, boom retracted, jib retracted.
SWING RIGHT(Max): 360°, from platform control, boom
approximately 45° elevation, boom retracted, jib retracted.
SWING LEFT(Max): 360°, from platform control, boom
approximately 45° elevation, boom retracted, jib retracted.
TELESCOPE OUT: from platform control, boom 20°, 500 lb
(226 kg) capacity selected.
TELESCOPE IN: from platform control, boom 20°, 500 lb (226
kg) capacity selected.
JIB TELESCOPE IN: from platform control, boom horizontal, jib
horizontal, 500 lb (226 kg) capacity selected.
JIB TELESCOPE OUT: from platform control, boom horizontal,
jib horizontal, 500 lb (226 kg) capacity selected.
DRIVE FORWARD (Max): high speed - low torque setting,
drive 200 ft (61 m) front wheels to front wheels. Timed after
machine has obtained maximum speed.
DRIVE REVERSE (Max): high speed - low torque setting, drive
200 ft (61 m) front wheels to front wheels Timed after machine
has obtained maximum speed.
DRIVE FORWARD (Creep Max): high torque - low speed set-
ting, platform speed knob at full creep
DRIVE REVERSE (Creep Max): high torque - low speed set-
ting, platform speed knob at full creep
DRIVE FORWARD (Elevated Max - Boom Beyond Trans-
port): high speed - low torque setting, platform speed knob
out of creep, Lift boom above transport, drive forward 50 ft (15
m).
DRIVE REVERSE (Elevated Max - Boom Beyond Transport):
high speed - low torque setting, platform speed knob out of
creep, Lift boom above transport, drive backward 50 ft (15 m).
CLEARSKY:
25
0
1
NO: ClearSky Telematics system not installed.
YES: ClearSky Telematics system installed.
0
CRIBBING OPTION:
26
0
1
NO: Cribbing Option is disabled.
YES: Cribbing Option is enabled.
0
FUEL TANK SIZE:
27
0
1
31 Gallon tank.
52 Gallon tank.
0
ALARM/HORN:
28
0
1
SEPERATE: Separate alarm and horn.
COMBINED: combination alarm/horn.
0
4150364 F
Table 6-5. Machine Configuration Programming Information
Configuration Digit
Number
Description
Default
Number
