3120720 7-23
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
552 to 553 Not Used
554 4460742 Connector, Male - 2 Position (LRG425 With EFI
Only) 1
555 to 556 Not Used
557 4460871 Socket, Female AR
558 to 566 Not Used
4922513 VALVE HARNESS ASSEMBLY Ref 3/D
601 4922513 Harness, Assembly 1
602 to 635 Not Used
636 4460880 DIN Connector 15
637 4460320 Connector, Female - 2 Position 2
638 4460267 Pin, Male 5
639 4460424 Connector, Male - 2 Position 1
640 4460268 Pin, Female 5
641 4460871 Socket, Female 28
642 to 644 Not Used
645 4460326 Connector, Male - 3 Position 1
646 4460445 Connector, Female - 3 Position 1
647 to 651 Not Used
STANDARD HARNESS COMPONENTS Ref
701 4922621 Tilt Indicator Harness 1
701A 4460226 Pin 4
701B 4460224 Connector, Female - 6 Position 1
701C 4460227 Pin 4
701D 4460225 Connector, Female - 6 Position 1
701E 4460871 Socket, Female 4
702 Not Used
703 See Note Pump Harness (Note: Not Available for Pur-
chase.) 1
703A 7007497 Plug (Pump End) 1
703B 7007498 Plug (Engine Harness End) 1
704 See Note Controller Harness Assembly (Lift and Swing)
(Note: Not Available for Purchase.) 1
704A 7022819 Plug, Male - 8 Position (Natural) 1
704B 4460871 Socket, Female 8
705 See Note Controller Harness/Circuit Board Assembly (Drive
and Steer) (Note: Not Available for Purchase.) 1
705A 7022825 Plug, Male - 8 Position (Black) 1
705B 4460871 Socket, Female 7
706 See Note Ford Engine Harness (For replacement parts refer to
Ford engine dealer (Ford EFI Engine Machines)
(Note: Not Available for Purchase.) 1
FIGURE 7-3. HARNESS COMPONENTS INSTALLATION (ADE SYSTEM) (SN 0300061927 TO SN
0300063909) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
