2-62 3120720
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
309 7020120 Bell Housing 1
7022180 Ring Gear 1
Flywheel & Coupling Assembly AR
1660218 Flywheel & Coupling Assembly - 13 Tooth Pump
(2000126 Engine Prior to SN 0300029318) 1
309A 1660249 Coupling - 13 Tooth Pump (Original Equipped) (was p/n
7012656) (2000126 Engine Prior to SN 0300029318) 1
7019976 Flywheel & Coupling Assembly - 15 Tooth Pump
(2000149 Engine SN 0300029318 SN 0300037117) 1
1660250 Coupling, Pump - 15 Tooth Pump (2000149 Engine
SN 0300029318 SN 0300037117) (was p/n 7016662) 1
310 7022153 Water Pump Assembly (was p/n 7016638) 1
311 Not Used
312 70002307 Gasket, Exhaust (Manifold to Pipe) 1
7022143 Gasket, Exhaust (Manifold to Head) (Not Shown) 1
313 4360157 Switch, Water Temperature (Not Shown) 1
314 7019921 Belt 1
7019929 Pulley, Idler (Tensioner Assembly) 1
315 7025126 Manifold, Intake (was p/n 7019923) 1
316 7019924 Manifold, Exhaust (Not Shown) 1
317 7019925 PCV Valve (Not Shown) 1
318 7019930 Coil, Ignition 1
7019931 Wire Set - Spark Plug 1
7019932 Plug, Spark 4
319 7022178 Sensor, Crankshaft (Not Shown) 1
320 7022150 Belt, Timing 1
MUFFLER INSTALLATIONS (Prior to SN 0300029318) Ref
0255864 Standard Spark Arresting Ref —
0255865 Optional Catalytic Ref —
401 Muffler Options: 1
3220097 Standard Spark Arresting
3220098 Optional Catalytic
402 0340041 Band 2
403 0902212 Bracket, Muffler 1
404 0641508 Bolt 5/16in-18NC x 1in 4
405 4711500 Flatwasher 5/16in Thin 8
406 3311505 Locknut 5/16in-18NC 4
407 1320019 Clamp, Exhaust 1
MUFFLER INSTALLATIONS (SN 0300029318 to
SN 0300037117) Ref
0256685 Standard Spark Arresting Ref 2
0256686 Optional Catalytic Ref —
451 Muffler Options: 1
3220105 Standard Spark Arresting
3220106 Optional Catalytic
FIGURE 2-13. FORD ENGINE INSTALLATIONS - LRG423 (PRIOR TO SN 0300037117) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
