2-70 3120720
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
310 7022153 Water Pump Assembly 1
7019985 Pulley, Water Pump 1
7019982 Inlet, Water Pump (Not Shown) 1
7022156 Thermostat Assembly (Not Shown) 1
311 7022178 Sensor, Crank Shaft (Not Shown) 1
312 70002307 Gasket, Exhaust (Manifold to Pipe) 1
7022143 Gasket, Exhaust (Manifold to Head) (Not Shown) 1
70219924 Manifold, Exhaust (Not Shown) 1
313 Use7025126 Manifold, Intake (was p/n 7019923) 1
7025125 Gasket, Intake Manifold 1
314 Spark Plug Options (Not Shown): 4
See Note SN 0300037117 to SN 0300039820 (2000156 Engine)
(Note: Not Available for Purchase.)
7019932 SN 0300039820 to SN 0300068000 (2000160 Engine)
Wire Set, Spark Plug (Not Shown) Options: 1
7022157 SN 0300037117 to SN 0300039820 (2000156 Engine)
7019931 SN 0300039820 to SN 0300068000 (2000160 Engine)
7019930 Coil, Ignition 1
315 Use 7027402 Belt, Drive (was p/n 7019979) 1
7019978 Tensioner, Belt (Not Shown) 1
316 7022151 Cap, Oil Fill 1
317 7022150 Belt, Timing 1
MUFFLER INSTALLATIONS Ref
0258390 Standard Spark Arresting Ref 1
0258391 Optional Catalytic Ref 1
0258570 UL Machines Ref 1
401 Muffler Options: 1
3220113 Standard Spark Arresting
3220114 Optional Catalytic
402 0340046 Band 2
403 0902309 Bracket, Muffler 1
404 0641507 Bolt 5/16in-18NC x 7/8in 4
405 4711500 Flatwasher 5/16in Thin 8
406 3311505 Locknut 5/16in-18NC 4
407 4567073 Tube, Exhaust 1
408 4845667 Weldment, Exhaust Tube (UL Machines Only) 1
409 3900232 Bolt, Button Head 3/8in-16NC x 1-1/4in (UL Machines
Only) 5
410 4751600 Flatwasher 3/8in Regular (UL Machines Only) 7
411 3311601 Nut 3/8in-16NC (UL Machines Only) 5
412 0902472 Bracket, Exhaust Support (UL Machines Only) 1
413 3220111 Spark Arrestor (UL Machines Only) 1
FIGURE 2-14. FORD ENGINE INSTALLATIONS - LRG425 WITH CARBURETOR (SN 0300037117 TO
SN 0300068000) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
