3120720 1-9
S
E
C
T
I
O
N
1
F
R
A
M
E
SECTION 1 FRAME
204 Kingpin Options: 4
3422330 Prior to SN 0300047411
3422753 SN 0300047411 to SN 0300068000
205 0681610 Bolt 3/8in-16NC x 1-1/4in (Grade 8) 8
206 Pin, Steer Cylinder Options: 2
3422327 Prior to SN 0300061704
3422902 SN 0300061704 to SN 0300068000
207 3841143 Shaft, Keeper 6
208 0641608 Bolt 3/8in-16NC x 1in 4
209 0100011 Compound, Locking AR
210 3422326 Pin, Steer Cylinder 2
211 0641612 Bolt 3/8in-16NC x 1-1/2in 2
212 3311605 Locknut 3/8in-16NC (Prior to SN 0300061704) 2
213 Tie-Rod Options: 1
3841234 Prior to SN 0300061704
3841510 SN 0300061704 to SN 0300068000
214 3323002 Nut, Jam 1-1/4in-12NF (RH Threads)
(Prior to SN 0300061704) 1
215 0561138 End, Tie-Rod (Right Side/RH Threads)
(Prior to SN 0300061704) 1
216 0561139 End, Tie-Rod (Left Side/LH Threads)
(Prior to SN 0300061704) 1
217 3300229 Nut, Jam 1-1/4in-12NF (LH Threads)
(Prior to SN 0300061704) 1
218 0682014 Bolt 5/8in-11NC x 1-3/4in (Grade 8)
(Prior to SN 0300061704) 2
219 0682016 Bolt 5/8in-11NC x 2in (Grade 8) (Prior to SN 0300061704) 2
220 3312002 Nut, Jam 5/8in-11NC (Prior to SN 0300061704) 4
221 Thrustwasher Options: 2
4740391 Prior to SN 0300038047
4740463 SN 0300038047 to SN 0300068000
222 4740111 Thrustwasher 6
223 3780187 O-Ring (Prior to SN 0300038047) 8
224 4640812 Valve Relief (Prior to SN 0300038047 Only) 4
225 2160002 Fitting, Grease (Prior to SN 0300038047 Only) 4
226 0961977 Bearing 2
227 Pin Options: 2
3422328 Prior to SN 0300061704
3422903 SN 0300061704 to SN 0300068000
228 0100063 Loctite RC609 (Prior to SN 0300061704) AR
229 Bushing, Composite Options: 4
0961850 Prior to SN 3030008047
0962131 SN 0300038047 to SN 0300068000
230 Thrustwasher Options: 2
4740449 Prior to SN 0300038047
4740256 SN 0300038047 to SN 0300068000
FIGURE 1-2. 4WD FRONT AXLE AND STEERING INSTALLATIONS (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
