2-128 3120720
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
.
FIGURE 2-29. HOODS & LIFTING PLATE INSTALLATIONS - WITH NOISE REDUCTION (SN
0300027943 TO SN 0300068000)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
NOTE: Steel Hood Replacement Kits are available for
machines built with Deutz engines. Purchase
p/n 1001126286. No kits are available for machines built
with Continental, Ford or Isuzu Engines. Ref
HOODS INSTALLATIONS Ref
0256830 Standard Ref 7/G
0258578 UL (SN 0300039457 to SN 0300068000) Ref 3
0270529 ISUZU (SN 0300057373 to SN 0300068000) Ref 1/A
1 Hood Assembly - Engine Side Options: 1
2680420 Standard (Prior to SN 0300038047)
2680449 Standard (SN 0300038047 to SN 0300068000)
2680443 UL
2600209 Hinge
1A 3960464 Seal 65in/1.67m
3960462 Seal 61in/1.55m
1B 2940088 Latch 1
2 Hood Assembly - Tank Side Options: 1
2680421 Standard (Prior to SN 0300038047)
2680448 Standard (SN 0300038047 to SN 0300068000)
2680437 UL
2600233 Hinge
2A 2940088 Latch 2
2B 3960438 Seal 53in/1.35m
2C 3960464 Seal 83in/2.11m
2D 3960462 Seal 55in/1.4m
3 Hood Assembly- Engine Spacer Options: 1
2680435 Standard (Prior to SN 0300038047)
2680450 Standard (SN 0300038047 to SN 0300068000)
2680435 UL
3A 3960453 Seal 68in/1.73m
3B 7023366 Bracket 1
4 Bracket, Hood Mounting Options: 1
0902138 Prior to SN 0300035860 1
0902416 SN 0300035860 to SN 0300068000 1
5 0902351 Bracket, Hood Mounting 1
6 3539934 Plate, Seal 1
7 3960389 Seal 3.5ft/1m
8 Bracket, Latch Options: 1
0902358 Prior to SN 0300038808
0902491 SN 0300038808 to SN 0300068000
9 0902223 Bracket, Latch 1
10 0902143 Bracket, Latch 1
11 3520033 Plug, Hole 2
12 0902161 Bracket, Hood Spacer Mounting 1
13 0940071 Bumper 5
14 0630507 Bolt, Carriage 1/2in-13NC x 1-1/4in 6
15 0641608 Bolt 3/8in-16NC x 1in AR
