3120720 5-7
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-3. PLATFORM LEVEL CYLINDER ASSEMBLIES - 600SJ & 660SJ
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
PLATFORM LEVEL CYLINDER ASSEMBLIES Ref
1683253 Prior to SN 0300024714 Ref 1/B
1683418 SN 0300024714 to SN 0300068000 Ref D
1 Barrel Weldment Options: 1
1683254 Prior to SN0300024714 (Note: Includes Item 1A)
1683419 SN 0300024714 to SN 0300052687
(Note: Includes Item 1A)
1683952 SN 0300052687 to SN 0300068000 (Note: Item
1A not included - Purchase Separately)
1A 0961951 Bushing, Composite 2
2 Rod Weldment Options: 1
1683333 Prior to SN0300052687 (Note: Includes Item 2A)
1683963 SN 0300052687 to SN 0300068000 (Note: Item
2A not included - Purchase Separately)
2A 0961951 Bushing, Composite 2
3 3480188 Piston 1
4 1683055 Head 1
5 0961894 Bushing, Tapered 1
6 4566468 Spacer 1
7 4640509 Cartridge, Valve 1
2900792 Seal Kit - 4640509 Valve 1
8 2220885 Plug, O-Ring 1
9 3931620 Capscrew, Socket Head 3/8in-16NC x 1-1/4in 8
10 3760369 Ring, Washer 1
11 0100011 Compound, Locking AR
12 0100038 Primer, Locking AR
13 Use 2901301 Seal 2
14 Use 2901301 Ring, Lock 2
15 Use 2901301 O-Ring 1
16 Use 2901301 Ring, Back-up 1
17 Use 2901301 Ring, Wear 1
18 Use 2901301 O-Ring 1
19 Use 2901301 Ring, Back-up 1
20 Use 2901301 Seal, Rod 1
21 Use 2901301 Wiper 1
22 Not Used
23 Cartridge, Valve Options: 1
4640509 Prior to SN 0300024714
4640932 SN 0300024714 to SN 0300068000
Seal Kit Options: 1
2900792 4640509 Valve (Prior to SN 0300024714)
7011112 4640932 Valve (SN 0300024714 to
SN 0300068000)
24 Plug, O-Ring Options: AR
2220885 Prior to SN 0300024714 4
2220883 SN 0300024714 to SN 0300068000 8
25 0630535 Screw, Socket Head 1/4in-20NC x 1-1/8in 3
— — — — — — — — — —
100 2901301 Seal Kit (Includes Items 13-21) 1
