7-20 3120720
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
FIGURE 7-3. HARNESS COMPONENTS INSTALLATION (ADE SYSTEM) (SN 0300061927 TO SN
0300063909)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
Note: SN 0300063910 to SN 0300064498 use either
p/n 0861388 or p/n 0861477 platform console box.
Determine appropriate console by the presence of
(2) white 15 position connectors inside console
box. If present, use Figure 7-13. If not present, use
Figure 7-14. Ref
4922509 PLATFORM BOX HARNESS ASSEMBLY Ref 3/D
1 4922509 Harness, Console Box 1
2 to 18 Not Used
19 4460866 Terminal, 19 Pin Receptacle 1
20 4460874 Connector - 35 Position (Natural) 1
21 4460875 Connector - 35 Position (Gray) 1
22 4460873 Connector - 35 Position (Black) 1
23 4460871 Socket, Female 48
24 4460464 Pin, Male (16 Gauge) 7
25 4460879 Terminal, Housing 2 Position 1
26 4460887 Terminal, (12 Gauge) 2
27 to 29 Not Used
30 4460418 Connector - 6 Position 4
31 4460419 Terminal, Female 12
32 4120035 Base, Light 7
33 to 35 Not Used
36 4460225 Connector - 6 Position 1
37 4460227 Pin, Male 6
38 to 40 Not Used
41 4460508 Pin, Male (12 Gauge) 3
42 Not Used
PLATFORM BOX ASSEMBLY COMPONENTS Ref
101 4460428 Connector, Strain Relief 2
102 4460470 Nut, Conduit 1
103 4460471 Washer 1
104 1060330 Cable, Electrical - 16/3 7ft/2.1m
105 4460071 Connector, Strain Relief 1
106 4460226 Socket, Female 2
107 4922485 Harness, Analyzer Cable (Not Shown - Located on
bottom front of console box) 1
4460871 Terminal, Socket 4
4460761 Housing - 4 Position 1
4460227 Pin 4
