7-14
3120720
SECTION 7
ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
572
2400061
Fuse (Ford Engine Only)
2
573
2400060
Holder, Fuse (Ford Engine Only)
2
574
4460449
DIN Connector without Diode
1
575 to 577
Not Required
578
4460418
Connector, 6 Position (Ford Engine - UL
Machines Only)
1
579
4460419
Terminal, Female (Ford Engine - UL Machines
Only)
6
580
3990010
Diode, 6 Amp (Ford Engine - UL Machines Only)
1
581
4460777
Housing - 4 Position (Continental, Isuzu & Deutz
Only) (SN 0300044047 to SN 0300061927)
1
582
4460591
Terminal, Lock (Continental, Isuzu & Deutz Only)
(SN 0300044047 to SN 0300061927)
1
583
4460589
Socket (Continental, Isuzu & Deutz Only)
(SN 0300044047 to SN 0300061927)
3
584
4460608
Seal, Cable (Continental, Isuzu & Deutz Only)
(SN 0300044047 to SN 0300061927)
3
585
Not Used
586
4460742
Connector, 2 Position (Ford Engine Only)
1
587
See Note
Dual Fuel Shut-Off Filter Harness (Note: Not
Available for Purchase.)
1
7023679
Electrical Connector Kit (Includes [1] 2 Posi-
tion Connector, 2 Pins & 2 Seals)
1
STANDARD HARNESS COMPONENTS
Ref
Note: Numbered Wiring Starts With SN 0300035129
Ref
601
See Note
Tilt Indicator Harness (Note: Not Available for
Purchase.)
1
601A
See Note
Pin (Prior to SN 0300026233)
AR
4460268
Socket, Female (SN 0300026233 to
SN 0300061927)
6
601B
See Note
Plug (Prior to SN 0300026233)
1
4460224
Connector, Female - 6 Position (SN 0300026233
to SN 0300061927)
1
Note: Prior to SN 0300026233, # 601A & 601B are
part of Valve Harness. See Valve Harness.
Ref
602
See Note
Throttle Actuator/Controller Harness (Continental,
Isuzu & Deutz) (Note: Not Available for Purchase.)
1
Use 2910000
Throttle Actuator and Controller Assembly
(Was p/n 0060033)
1
7008833
Mounting Clamp Kit (Not Shown)
1
7008836
Spring, Retract (Not Shown)
1
602A
See Note
Throttle Actuator & Harness (Note: Not
Available - Purchase p/n 2910000.)
1
7016336
Boot Kit
1
602B
See Note
Pin, Male (Note: Not Available for
Purchase.)
9
602C
See Note
Connector, Male (Note: Not Available for
Purchase.)
1
602D
2910001
Controller & Harness (Purchase p/n 2910000)
1
FIGURE 7-2. HARNESS COMPONENTS INSTALLATION (PRIOR TO SN 0300061927)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
