3120720 7-21
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
BOOM CABLES INSTALLATION Ref
0270733 600S - 2WS Ref 3
0270738 600SJ - 2WS Ref 2
0270736 660SJ - 2WS Ref 2
201 Harness, Main Boom Options: 1
4922468 600S - 2WS
4922466 600SJ - 2WS
4922467 660SJ - 2WS
201A 1060896 Cable Options: AR
600S - 2WS 67ft/20.4m
600SJ - 2WS 69ft/21m
660SJ - 2WS 75ft/22.8m
201B 4460465 Socket, Female - #16 22
201C 4460865 Connector (19 Pin) 1
201D 4460509 Socket, Female - #12 8
201E 4460473 Clamp, Cable 1
201F 4460466 Seal, Plug 4
202 1060494 Cable, Electrical - 12/3 Options: (Does not include
plug ends) AR
600S - 2WS 69.5ft/21.8m
600SJ - 2WS 71ft/21.6m
660SJ - 2WS 77ft/23.5m
202A 4460205 Plug, Male (110V) 1
202B 4460134 Connector, Female (110V) 1
203 1060680 Cable, Electrical - 18/2 Boom Length AR
600S - 2WS 55.5ft/16.9m
600SJ/660SJ - 2WS 15ft/4.6m
204 to 206 Not Used
207 Sleeve, Nylon Options: AR
4100026 600S - 2WS 10ft/3.0m
Not Required 600SJ/660SJ - 2WS
GROUND CONTROL BOX DIAGRAMS Ref
4933169 Deutz Engine Ref 5/G
4933155 Ford EFI Engine Ref 5/G
301 2920129 Bulb, Light 6
302 to 305 Not Used
306 4460871 Socket, Female AR
307 2400065 Fuse, 30Amp (Not Shown) 1
308 2400066 Fuse, Holder W/Cover (Not Shown) 1
4922475 GROUND CONTROL HARNESS ASSEMBLY Ref 5/F
401 to 433 Not Used
434 4460419 Terminal, Female 21
435 4460418 Connector - 6 Position 7
FIGURE 7-3. HARNESS COMPONENTS INSTALLATION (ADE SYSTEM) (SN 0300061927 TO SN
0300063909) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
