1-16 3120720
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
TIRE AND WHEEL INSTALLATIONS OPTIONS: Ref
0255299 Pneumatic - Denman Tires (Prior to SN 0300033658) Ref 1
0257875 Pneumatic - Galaxy Tires
(SN 0300033658 to SN 0300064780) Ref 1
0271618 Pneumatic - OTR Tires
(SN 0300064780 to SN 0300068000) Ref 1
0272297 Pneumatic W/Sealant - OTR Tires
(SN 0300068874 to SN 0300068000) Ref 1
0255302 Foam-Filled - Denman Tires (Prior to SN 0300033703) Ref 1
0257874 Foam-Filled - Galaxy Tires
(SN 0300033703 to SN 0300064780) Ref 1
0271619 Foam-Filled - OTR Tires
(SN 0300064780 to SN 0300068000) Ref 1
Note: Recommend using Galaxy Tires in place of Den-
man. Ref
Tire and Wheel Assembly Options: (See Items 101 to 107
for Breakdown) 2
Pneumatic (Prior to SN 0300033658)
0255298 Denman Tire (Left Side) 4/D
0255297 Denman Tire (Right Side) 4/D
Pneumatic (SN 0300033658 to SN 0300064780)
0257865 Galaxy Tire (Left Side) 1/A
0257864 Galaxy Tire (Right Side) 1/A
Pneumatic (SN 0300064780 to SN 0300068000)
0271614 OTR Tire (Left Side) A
0271615 OTR Tire (Right Side) A
Pneumatic (SN 0300066874 to SN 0300068000)
0272317 W/Sealant - OTR Tire (Left Side) A
0272318 W/Sealant - OTR Tire (Right Side) A
Foam-Filled (Prior to SN 0300033703)
0255301 Denman Tire (Left Side) 3/B
0255300 Denman Tire (Right Side) 3/B
Foam-Filled (SN 0300033703 to SN 0300064780)
0257867 Galaxy Tire (Left Side) 1/A
0257866 Galaxy Tire (Right Side) 1/A
Foam-Filled (SN 0300064780 to SN 0300068000)
0271616 OTR Tire (Left Side) A
0271617 OTR Tire (Right Side) A
Note: Assemblies may require ballast/foam filling to
manufacturer’s specifications prior to installing on a
machine. Refer to Operation & Safety or Service &
Maintenance Manuals. Purchase individual tire and/
or rim only if able to foam fill tire & wheel assembly,
otherwise, purchase complete assembly. Ref
FIGURE 1-4. TIRE AND WHEEL DRIVE INSTALLATIONS
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
